本機特別為潤滑油行業量身定做。融合了各種不同封口機的優點于一體。能完成對各種超小口徑(10MM)到超大口徑(200MM)以及尖嘴高蓋異型產品的完美封口,為客戶帶來經濟效益。
主要特點
一、適用范圍
本機特別為潤滑油行業量身定做。融合了各種不同封口機的優點于一體。能完成對各種超小口徑(10MM)到超大口徑(200MM)以及尖嘴高蓋異型產品的完美封口,為客戶帶來經濟效益。
二、特點:
1、感應頭特有隧道式結構,多方位立體加熱模式使封口效果更加理想;
2、開機無需預熱,操作簡單,維護方便;
3、選用優質不銹鋼制造,產品設計合理,美觀大方,符合GMP要求;
4、主機發生器采用美國進口晶體管,CPU模塊控制,功率可調;
5、特有開關電源設計,保證功率恒定輸出;
6、水冷連續式工作,高效高速,可全天候長時間運行;
7、可方便靈活的與生產線配套使用;
Major characteristics:
This machine is specially designed for the lubricant industry. It combines the advantages of various sealing machines and can perfectly seal the bottles diameter of 10 mm to 200 mm. Also some irregular bottles. So it will bring the biggest economic benefit for the customer.
1. The sensing head with tunnel structure, unique multi-dimensional stereoscopic heating mode can seal efficiently.
2.Without preheating, simple operation and convenient maintenance.
3.High quality stainless steel manufacturing, product design is reasonable,beautiful and easy, in line with the GMP requirements;
4.Host machine use the latest imported transistor, the CPU control and adjustable power.
5.Special switching power supply ensure the constant power output.
6.The water-cooled continuous work,efficient and high speed, can be the whole day running;
7.Convenient and flexible with production line
主要技術參數
1、封口范圍:Φ10~80MM 80~200MM
2、適用電力:AC220V±10% 50HZ
3、輸出功率:4000W(MAX)
4、封口速度:約400瓶/分鐘(以PE瓶口徑30mm為例)
5、包裝尺寸:600*600*1300MM
6、重量:95KG
